Monteringsflange for bronzestævnrør Ø 40 mm
Køb nu og modtag den mellem 08.12.25 og 10.12.25
Leveringsdatointervallet giver dig en indikation af, hvor lang tid det vil tage at modtage varen. Det er baseret på ordrehåndteringstid, leveringsmetode og produkttilgængelighed.
Bronze mounting flange for VETUS BL40 series stern tubes.Bronze mounting flange for VETUS BL40 series stern tubes.
The shaft end of the bronze stern tube is provided with an outer cutless bearing and a mounting flange.
The slots in the tube are designed for easy replacement of the cutless bearing.
Stern tubes are available in stainless steel AISI 316 and aluminium 5083 to special order.
A second mounting flange (3) can be ordered separately, if required.
The shaft end of the bronze stern tube is provided with an outer cutless bearing and a mounting flange.
The slots in the tube are designed for easy replacement of the cutless bearing.
Stern tubes are available in stainless steel AISI 316 and aluminium 5083 to special order.
A second mounting flange (3) can be ordered separately, if required.
| Fabrikant | Vetus |
|---|---|
| Aksel Diameter (mm) | 40 mm |
| Diameter D (inches) | 1 9/16 |
| Length U (mm) | 96 |
| Length T (mm) | 104 |
| Length S (mm) | 116 |
| Length R (mm) | 23 |
| Length V (inches) | 7/16 |
| Length U (inches) | 3 3/4 |
| Length T (inches) | 4 1/8 |
| Length S (inches) | 4 9/16 |
| Length R (inches) | 7/8 |
| Diameter D (mm) | 40 |
| Length V (mm) | 10,5 |
